Equipment List

Learn More

Coordinate Measuring System


Giddings & Lewis Cordax Apollo II
Model RS-50 DCC
High Performance Coordinate Measuring System.
Measuring Envelope 40" X 48" X 30" Tall
Equipped with G&L Direct Inspect Inspection Software & Direct Design Reverse Engineering Software

Computer Aided Design System


Two Stations
SolidWorks 2012
Complete 3D-Modeling Capability
Full Translation Proficiency with Most Software

Wire E.D.M.


Pratt & Whitney
Model W1
5-Axis (Independent UV) Fanuc Control
Maximum Work Piece 13.8" X 17.7" X 10"
Electronic Z Axis
Sodick Model AQ535L
Maximum Travels: X=21.6", Y=13.7", Z=11.8"
Maximum Weight of Work Piece Is 1,496 Pounds


OKK Machining

(Click on Image to Enlarge)

OKK Machining

Bender

(Click on Image to Enlarge)

 Bender

Final Form Casket Bridge Die

(Click on Image to Enlarge)

Final Form Casket Bridge Die

CMM Inspection

(Click on Image to Enlarge)

CMM Inspection


Presses


Hamilton 1200
Ton Ser. 2706


4 Point, Single Action
72" X 108" Ram & Bolster
18" Stroke
30" Ram Adjustment
Complete with Air Cushions

Hamilton 900
Ton TS-1249


88" X 124" Ram & Bolster
24" Stroke
60" Maximum Shut Height
3 - 45-Ton Air Cushions
Clearing 250 Ton Straight Side, 72" X 42" Ram, 30" Maximum Shut Height

Minster 60
Ton OBI


35 Ton Obi
120 Strokes per Minute
10 1/4" Maximum Shut Height
Dallas Stock Feeder & Leveler .090" X 36" X 30" Maximum Index

Cooper-Weymouth™ Servo Feed .125 X 36"


Version 300 Ton S2-300-96-60t


Automatic Decrimping Machine

(Click on Image to Enlarge)

Automatic Decrimping Machine

CMM Inspection

(Click on Image to Enlarge)

CMM Inspection

Robot Corner Lid Welder

(Click on Image to Enlarge)

Robot Corner Lid Welder

MAC Wire W1

(Click on Image to Enlarge)

MAC Wire W1


Milling Machines


OKK Vertical Machining
Center


30" X 60" X 24"
20-Station Tool Changer

Topwell™ CNC Vertical Milling Machine


20" X 50" X 24"
5.5" Spindle Travel

Cincinnati™
Hydrotel


120" X 28" X 14"
Maximum Work Height 32"
Depth Trace Duplicating Attachment
Sony 3-Axis Digital Readout

DeVlieg™
3H-48


Automatic Positioning
Capacity 48" Right to Left
36" Vertical
Complete Tooling

Bridgeport™ Model BR2J (3 Units)


Capacity 12" X 48"
Series I with Readouts

South Bend
Chipmaster™ II


1-Unit 5 HP
Capacity 10" X 50" with Readout
1-Unit with 2-Axis CNC


Material Handling System to Weigh and Stack Fasteners and Feed Totes

(Click on Image to Enlarge)

Material Handling System to Weigh and Stack Fasteners and Feed Totes

Wire EDM Machine

(Click on Image to Enlarge)

Wire EDM Machine

Radiator Core Insertion Machine

(Click on Image to Enlarge)

Radiator Core Insertion Machine

Robot welder Right Side Inside

(Click on Image to Enlarge)

Robot welder Right Side Inside


Grinders


Mattison™ High Powered Surface Grinders


1 Capacity 36" X 120" X 28" High Over Chucks
1 Capacity 16" X 48" Length X 16" High Over Chucks.

Okamoto™


ACC 12-24 DX Model Surface Grinder
Capacity 12" X 24"

Brown & Sharp


6" x 18" Micromaster Surface Grinder

Covel™


6" x 18" Surface Grinder


Casket Trim Die With Removable Subsets

(Click on Image to Enlarge)

Casket Trim Die With Removable Subsets

2 Stage Casket Bridge Die Lower

(Click on Image to Enlarge)

2 Stage Casket Bridge Die Lower

Automatic Decrimping Machine Tooling

(Click on Image to Enlarge)

Automatic Decrimping Machine Tooling

Progressive Die to Blank Bracket

(Click on Image to Enlarge)

Progressive Die to Blank Bracket


Fabrication Equipment


Miller


1 250-Amp MIG Welder
1 500-Amp TIG Welder

Cincinnati


1 1/4" X 10-Foot Mechanical Gap Shear
1 10-Foot Press Brake

Hypertherm


MAX 43 Plasma Cutter
1/2" Capacity

Airco


450 AC/DC Arc Welder


Automotive Material Processing System

(Click on Image to Enlarge)

Automotive Material Processing System

Die Pic Showing Wired Sections

(Click on Image to Enlarge)

Wired Sections

Casket Lid Folder

(Click on Image to Enlarge)

Casket Lid Folder

MAC Grinder

(Click on Image to Enlarge)

MAC Grinder


Service & Transport Equipment


10-Ton Overhead Bridge Crane Servicing Main Bay
5 Ton Overhead Bridge Crane in Machining Area

Fork Lift Capacity up to 38,000-Pounds
Ford™ F800 Box Van; 16,800-Pounds Capacity

Warehouse & Distribution Building


100,000-Square Feet
5-Bay Loading Dock Area
